using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Linq;
using System.Text;
using System.Windows.Forms;
using System.IO.Ports;
//using Microsoft.VisualBasic.Devices;
namespace 模拟三菱PLC
{
public partial class Form1 : Form
{
int M0toM7_value = 0;
private SerialPort port = new SerialPort("COM1", 9600, Parity.Even, 7, StopBits.One);
int mygetM0M7_value()
{
int value = 0;
//读取M0状态
if (lable_M0.BackColor == Color.Red)
{
value += 0x01;
}
//读取M1状态
if (lable_M1.BackColor == Color.Red)
{
value += 0x02;
}
//读取M2状态
if (lable_M2.BackColor == Color.Red)
{
value += 0x04;
}
if (lable_M3.BackColor == Color.Red)
{
value += 0x08;
}
if (lable_M4.BackColor == Color.Red)
{
value += 0x10;
}
if (lable_M5.BackColor == Color.Red)
{
value += 0x20;
}
if (lable_M6.BackColor == Color.Red)
{
value += 0x40;
}
if (lable_M7.BackColor == Color.Red)
{
value += 0x80;
}
return value;
}
public Form1()
{
InitializeComponent();
}
private bool MyBytesisEquals(byte[] b1, byte[] b2)
{
if (b1.Length != b2.Length) return false;
if (b1 == null || b2 == null) return false;
for (int i = 0; i < b1.Length; i++)
if (b1[i] != b2[i])
return false;
return true;
}
void myopenport(String comport)
{
try
{
if (port.IsOpen)
port.Close();
port.PortName = comport;
port.Open();
}
catch (Exception ex)
{
MessageBox.Show(ex.ToString());
}
}
private void init()
{
cmb_COM.Items.Clear();
String[] ports = SerialPort.GetPortNames();
foreach (String portname in ports)
{
cmb_COM.Items.Add(portname);
}
Control.CheckForIllegalCrossThreadCalls = false;
port.ReadTimeout = 1000;
port.DataReceived += new SerialDataReceivedEventHandler(port_DataReceived);
cmb_COM.SelectedIndex = 0;
lable_M0.BackColor = Color.Green;
lable_M1.BackColor = Color.Green;
lable_M2.BackColor = Color.Green;
lable_M3.BackColor = Color.Green;
lable_M4.BackColor = Color.Green;
lable_M5.BackColor = Color.Green;
lable_M6.BackColor = Color.Green;
lable_M7.BackColor = Color.Green;
//myopenport("COM1");
;
byte[] bytes1 = { 1, 2, 3 };
byte[] bytes2 = { 2, 3,4 };
bool isequal = MyBytesisEquals(bytes1,bytes2);
//MessageBox.Show(isequal.ToString());
}
void port_DataReceived(object sender, SerialDataReceivedEventArgs e)
{
int len = port.BytesToRead;
byte[] readDatas = new byte[len];
port.Read(readDatas, 0, len);
bool isequal = MyBytesisEquals(readDatas, FXPLC.bytes_ReadM348);
if (isequal)
{
M0toM7_value = 0;
M0toM7_value = mygetM0M7_value();
System.Threading.Thread.Sleep(50);
byte[] newbytes = FXPLC.Gender_MBytes(M0toM7_value);
port.Write(newbytes, 0, newbytes.Length);
}
else
port.Write(FXPLC.response_wrong, 0, 1);
//MessageBox.Show(isequal.ToString());
//throw new NotImplementedException();
}
private void Form1_Load(object sender, EventArgs e)
{
init();
}
private void Form1_FormClosing(object sender, FormClosingEventArgs e)
{
if (port.IsOpen)
port.Close();
}
private void cmb_COM_SelectedIndexChanged(object sender, EventArgs e)
{
}
private void statusStrip1_ItemClicked(object sender, ToolStripItemClickedEventArgs e)
{
}
private void timer1_Tick(object sender, EventArgs e)
{
//Global.a=0;
if(port.IsOpen)
port.Write(FXPLC.bytes_ReadM348, 0, FXPLC.bytes_ReadM348.Length);
}
private void button1_Click(object sender, EventArgs e)
{
myopenport(cmb_COM.SelectedItem.ToString());
// timer1.Enabled = true;
}
private void lable_M0_Click(object sender, EventArgs e)
{
if (lable_M0.BackColor == Color.Red)
lable_M0.BackColor = Color.Green;
else
lable_M0.BackColor = Color.Red;
}
private void lable_M1_Click(object sender, EventArgs e)
{
if (lable_M1.BackColor == Color.Red)
lable_M1.BackColor = Color.Green;
else
lable_M1.BackColor = Color.Red;
}
private void lable_M2_Click(object sender, EventArgs e)
{
if (lable_M2.BackColor == Color.Red)
lable_M2.BackColor = Color.Green;
else
lable_M2.BackColor = Color.Red;
}
private void lable_M3_Click(object sender, EventArgs e)
{
if (lable_M3.BackColor == Color.Red)
lable_M3.BackColor = Color.Green;
else
lable_M3.BackColor = Color.Red;
}
private void lable_M4_Click(object sender, EventArgs e)
{
if (lable_M4.BackColor == Color.Red)
lable_M4.BackColor = Color.Green;
else
lable_M4.BackColor = Color.Red;
}
private void lable_M5_Click(object sender, EventArgs e)
{
if (lable_M5.BackColor == Color.Red)
lable_M5.BackColor = Color.Green;
else
lable_M5.BackColor = Color.Red;
}
private void lable_M6_Click(object sender, EventArgs e)
{
if (lable_M6.BackColor == Color.Red)
lable_M6.BackColor = Color.Green;
else
lable_M6.BackColor = Color.Red;
}
private void lable_M7_Click(object sender, EventArgs e)
{
if (lable_M7.BackColor == Color.Red)
lable_M7.BackColor = Color.Green;
else
lable_M7.BackColor = Color.Red;
}
}
}
